치수의구분(mm) d e f g h
이상 이하 d8 d9 e7 e8 e9 f6 f7 f8 g5 g6 h5 h6 h7 h8 h9
3 6 -30
-48		 -30
-60		 -20
-32		 -20
-38		 -20
-50		 -10
-18		 -10
-22		 -10
-28		 -4
-9		 -4
-12		 0
-5		 0
-8		 0
-12		 0
-18		 0
-30
6 10 -40
-62 		-40
-76		 -25
-40		 -25
-47		 -25
-61		 -13
-22		 -13
-28		 -13
-35		 -5
-11		 -5
-14		 0
-6		 0
-9		 0
-15		 0
-22		 0
-36
10 14 -50
-77		 -50
-93		 -32
-50		 -32
-59		 -32
-75		 -16
-27		 -16
-34		 -16
-43		 -6
-14		 -6
-17		 0
-8		 0
-11		 0
-18		 0
-27		 0
-43
14 18
18 24 -65
-98		 -65
-117		 -40
-61		 -40
-73		 -40
-92		 -20
-33		 -20
-41		 -20
-53		 -7
-16		 -7
-20		 0
-9		 0
-13		 0
-21		 0
-33		 0
-52
24 30
30 40 -80
-119		 -80
-142		 -50
-75		 -50
-89		 -50
-112		 -25
-41		 -25
-50		 -25
-64		 -9
-20		 -9
-25		 0
-11		 0
-16		 0
-25		 0
-39		 0
-62
40 50
50 65 -100
-146		 -100
-174		 -60
-90		 -6
-106		 -60
-134		 -30
-49		 -30
-60		 -30
-76		 -10
-23		 -10
-29		 0
-13		 0
-19		 0
-30		 0
-46		 0
-74
65 80
80 100 -120
-174		 -120
-207		 -72
-107		 -72
-126		 -72
-159		 -36
-58		 -36
-71		 -36
-90		 -12
-27		 -12
-34		 0
-15		 0
-22		 0
-35		 0
-54		 0
-87
100 120
120 140 -145
-208		 -145
-245		 -85
-125		 -85
-148		 -85
-185		 -43
-68		 -43
-83		 -43
-106		 -14
-32		 -14
-39		 0
-18		 0
-25		 0
-40		 0
-63		 0
-100
140 160
160 180
180 200 -170
-242		 -170
-285		 -100
-146		 -100
-172		 -100
-215		 -50
-79		 -50
-96		 -50
-122		 -15
-35		 -15
-44		 0
-20		 0
-29		 0
-46		 0
-72		 0
-115
200 225
225 250
250 280 -190
-271		 -190
-320		 -110
-162		 -110
-191		 -110
-240		 -56
-88		 -56
-108		 -56
-137		 -17
-40		 -17
-49		 0
-23		 0
-32		 0
-52		 0
-81		 0
-130
280 315
315 355 -210
-299		 -210
-350		 -125
-182		 -125
-214		 -125
-265		 -62
-98		 -62
-119		 -62
-151		 -18
-54		 -18
-54		 0
-25		 0
-36		 0
-57		 0
-89		 0
-140
355 400
400 450 -230
-327		 -230
-385		 -135
-195		 -135
-232		 -135
-290		 -68
-108		 -68
-131		 -68
-165		 -20
-47		 -20
-60		 0
-27		 0
-40		 0
-63		 0
-97		 0
-155
450 500

치수의구분(mm) js j k m n p r
이상 이하 js5 js6 js7 j5 j6 k5 k6 m5 m6 n6 p6 r6
3 6 ±2.5 ±4 ±6 +3
-2		 +6
-2		 +6
+1		 +9
+1		 +9
+4		 +12
+4		 +16
+8		 +20
+12		 +23
+15
6 10 ±3 ±4.5 ±7.5 +4
-2		 +7
-2		 +7
+1		 +10
+1		 +12
+6		 +15
+6		 +19
+10		 +24
+15		 +28
+19
10 14 ±4 ±5.5 ±9 +5
-3		 +8
-3		 +9
+1		 +12
+1		 +15
+7		 +18
+7		 +23
+12		 +29
+18		 +34
+23
14 18
18 24 ±4.5 ±6.5 ±10.5 +5
-4		 +9
-4		 +11
+2		 +15
+2		 +17
+8		 +21
+8		 +28
+15		 +35
+22		 +41
+28
24 30
30 40 ±5.5 ±8 ±12.5 +6
-5		 +11
-5		 +13
+2		 +18
+2		 +20
+9		 +25
+9		 +33
+17		 +42
+26		 +50
+34
40 50
50 65 ±6.5 ±9.5 ±15 +6
-7		 +12
-7		 +15
+2		 +21
+2		 +24
+11		 +30
+11		 +39
+20		 +51
+32		 +60
+41
65 80 +62
+43
80 100 ±7.5 ±11.5 ±17.5 +6
-9		 +13
-9		 +18
+3		 +25
+3		 +28
+13		 +35
+13		 +45
+23		 +59
+37		 +73
+51
100 120 +76
+54
120 140 ±9 ±12.5 ±20 +7
-11		 +14
-11		 +21
+3		 +28
+3		 +33
+15		 +40
+15		 +52
+27		 +68
+43		 +88
+63
140 160 +90
+65
160 180 +93
+68
180 200 ±10 ±14.5 ±23 +7
-13		 +16
-13		 +24
+4		 +33
+4		 +37
+17		 +46
+17		 +60
+31		 +79
+50		 +106
+77
200 225 +109
+80
225 250 +113
+84
250 280 ±11.5 ±16 ±26 +7
-16		 +16
-16		 +27
+4		 +36
+4		 +43
+20		 +52
+20		 +66
+34		 +88
+56		 +126
+94
280 315 +130
+ 98
315 355 ±12.5 ±18 ±28.5 +7
-18		 +18
-18		 +29
+4		 +40
+4		 +46
+21		 +57
+21		 +73
+37		 +98
+62		 +144
+108
355 400 +150
+114
400 450 ±13.5 ±20 ±31.5 +7
-20		 +20
-20		 +32
+5		 +45
+5		 +50
+23		 +63
+23		 +80
+40		 +108
+68		 +166
+126
450 500 +172
+132
